Product Details:

Place of Origin: China
Brand Name: TIPTOP
Certification: API
Model Number: Sucker Rod

Payment & Shipping Terms:

Minimum Order Quantity: 100pcs
Price: Negotiation
Packaging Details: Seaworthy Wooden Box
Delivery Time: 5~30 days
Payment Terms: T/T, L/C, D/A, D/P
Supply Ability: 20000 pieces per month
Detailed Product Description
Standard: API 11B Product Name: Sucker Rod
Material: Steel Advantage: Big Torque Bearing
Color: Black,silver Shape: Hollow
High Light:

oil field pumping units

,

oilfield sucker rods

High Strength Oil Well Drilling Tools API 11B Hollow sucker rods​





Introduction:

Hollow sucker rods is a special product used for “hypercoagulabitity,high-viscosity,and high waxy”crude oil in addition to injecting heat carrier (thermal oil,hot water,steam)and chemicals into underground or putting the cable to reduce viscosity and dissolve wax through the center of the rod hole,it can also be adopted into sand cut,Jie salt,small well oil extraction,aying oil extraction,as well as screw pump driving by use the characteristics of strong stiffness and big torque bearing.



Mechanical properties:

Strength level

Yield strength

σs (Mpa)

Tensile strength

σb (Mpa)

Elongation

δ %

Reduction of area

Ψ %

Impact toughness

AKJ

Hardness

HB

Level D ≥ 590 795-965 ≥ 10 ≥ 48 58.8 273-291
Level HL ≥ 795 965-1195 ≥ 10 ≥ 45 - 291-332
