|Application:||Directional Well And Deep Well||Size:||4 3/4''~8''|
|Connection:||NC38, NC50||Working Torque:||18 KN.m|
|Product Name:||Hydraulic-Mechanical Drilling Jar||Usage:||Jarring And Stuck Releasing Tool|
directional drilling tools,
downhole oil tools
Downhole Drilling Tools, Hydraulic-Mechanical Drilling Jar, 4 3/4''~8''
Hydraulic-Mechanical Drilling Jar is a jarring and stuck releasing tool. It integrates the up jar and down jar and can release the stuck accident occurring during drilling operation. The Drilling Jar is an ideal tool for directional well and deep well drilling.
Hydraulic-mechanical drilling jar integrates hydraulic principle with mechanical principle, it’s a new type drilling jar, which can suit for all kinds of drilling operations, and go with drilling tools assembly to descend the well when used. The drilling tools are often stuck due to many kinds of reasons in down hole when in normal drilling operations, and this type drilling jar is an effective tool for releasing stuck. When the drilling tools are stuck, it can make drilling jar generate upward or downward jarring force through lifting and landing the drill strings, so it can release resistance and the stick by many time jarring, and recover normal drilling operation promptly. Meanwhile avoid resistance and stick to become further accident, and cause larger economic losses. If releasing force is failed, it can be adjusted at anytime on sites and be easy to use.
We also produce H2S resistance jars, which adopt high quality import sulfur-resistance material.
Please email us for your hydraulic-mechanical drilling jar inquiries.
|Connection||Max. tensile load (KN)||Max. working torque
|Upward jarring force (KN)||downward jarring force (KN)|
|121(4 3/4)||44.5 (1 3/4)||NC38||1000||12||400±30||220±30|
|165(6 1/2)||57.2 (2 1/4)||NC50||1500||14||650±30||300±30|
|203(8)||70 (2 3/4)||6 5/8REG||2200||18||800±30||400±30|
